Trek marlin 6 generation 3 -M -2025

Frameset

Frame

Alpha Silver Aluminium, internal derailleur and dropper post routing, rack and kickstand mount, 135x5 mm ThruSkew

*Fork

Size: S
RockShox Judy, coil spring, preload, TurnKey lockout, 42 mm offset for 27.5" wheel, 100 mm QR, 100 mm travel

Size: M , ML , L , XL
RockShox Judy, coil spring, preload, TurnKey lockout, 46 mm offset for 29" wheel, 100 mm QR, 100 mm travel

Max compatible fork travel

120mm, XXS: 80mm

Wheels

Hub front

Formula DC-20, alloy, 6-bolt, 100 mm ThruSkew

Hub rear

Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5 mm QR

Skewer rear

173x5 mm QR

Rim

Bontrager Kovee, double-wall, Tubeless-Ready, 28-hole, 23 mm width, Presta valve

*Tyre

Size: S
Maxxis Ardent Race, tubeless ready, EXO casing, folding bead, 60 tpi, 27.5x2.35"

Size: S
Maxxis IKON, tubeless ready, EXO casing, folding bead, 60 tpi, 27.5x2.35''

Size: M , ML , L
Maxxis Ardent Race, tubeless ready, EXO casing, folding bead, 60 tpi, 29x2.35"

Size: M , ML , L , XL
Maxxis IKON, tubeless ready, EXO casing, folding bead, 60 tpi, 29x2.35''

Max tyre size

Frame: 29x2.40" (XXS: 26x2.40", XS & S: 27.5x2.40"), Fork: See manufacturer

Drivetrain

Shifter

Shimano U6000, 10-speed

Rear derailleur

Shimano CUES U6000 GS

*Crank

Size: S , M , ML
FSA Alpha Drive, 30T, 170 mm length

Size: L , XL
FSA Alpha Drive, 30T, 175 mm length

Bottom bracket

FSA, 73 mm, threaded cartridge, 122.5 mm spindle

Cassette

Shimano CUES LG300, LINKGLIDE, 11-48, 10-speed

Chain

Shimano LG500

Pedal

VP-536 nylon platform

Max. chainring size

1x: See FAQ, 2x: 36T, 3x: 42T

Components

Saddle

Bontrager Verse Short, stainless steel rails

*Seatpost

Size: S , M
Bontrager alloy, 31.6 mm, 12 mm offset, 330 mm length

Size: ML , L , XL
Bontrager alloy, 31.6 mm, 12 mm offset, 400 mm length

*Handlebar

Size: S
Bontrager alloy, 31.8 mm, 15 mm rise, 720 mm width

Size: M , ML , L , XL
Bontrager alloy, 31.8 mm, 15 mm rise, 750 mm width

Grips

Bontrager XR Trail Comp, nylon lock-on

*Stem

Size: S
Bontrager Comp, 31.8 mm, 7-degree, 35 mm length

Size: M , ML , L
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 50 mm length

Size: XL
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 60 mm length

Head set

Semi-integrated, 1-1/8"

Brake rotor

Tektro, 6-bolt, 160mm

*Brake Set

Size: S
Tektro HD-M276 hydraulic disc, short reach

Size: M , ML , L , XL
Tektro HD-M275 hydraulic disc

Rotor size

Max brake rotor sizes - Frame: 180mm (XXS: 160mm), Fork: see fork manufacturer

Weight

Weight

M - 14.50 kg / 31.97 lbs (with tubes)

Weight limit

This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
