Trek Domane AL5 Road Bike- M -2024

Frameset

Frame

100 Series Alpha Aluminium, tapered head tube, internal routing, mudguard mounts, flat-mount disc, UDH, 142x12 mm thru axle

Fork

Domane AL carbon, tapered carbon steerer, internal brake routing, fender mounts, flat mount disc, 12x100mm thru axle

Weight

Weight

56 - 9.85 kg / 21.72 lbs (with tubes)

Weight limit

This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lb).

Drivetrain

Shifter

Shimano 105 R7120, 12-speed

Front derailleur

Shimano 105 R7100, 31.8 mm clamp, down swing

Rear derailleur

Shimano 105 R7100, 36T max cog

*Crank

Size: 44
Shimano 105 R7100, 50/34, 165 mm length

Size: 49, 52
Shimano 105 R7100, 50/34, 170 mm length

Size: 54, 56
Shimano 105 R7100, 50/34, 172.5 mm length

*Bottom bracket

Size: 44, 49, 52, 54, 56
Shimano RS501 BSA

Size: 44, 49, 52, 54, 56
Prowheel PW-BB73+, 68/73 mm, threaded external

Cassette

Shimano 105 7101, 11-34, 12-speed

Chain

Shimano SLX M7100, 12-speed

Max. chainring size

1x: 50T, 2x: 50/34

Wheels

Hub front

Bontrager alloy, sealed bearing, CenterLock disc, 100x12 mm thru axle

Skewer front

Bontrager Switch thru axle, removable lever

Hub rear

Bontrager alloy, sealed bearing, CenterLock disc, Shimano 11-speed freehub, 142x12 mm thru axle

Skewer rear

Bontrager Switch thru axle

Rim

Bontrager Paradigm SL, Tubeless Ready, 24-hole, 21 mm width, Presta valve

Spokes

14 g stainless steel, black

Tyre

Bontrager R1 Hard-Case Lite, wire bead, 60 tpi, 700x32 mm

Max tyre size

38mm without mudguards, 35mm with mudguards

Components

Saddle

Selle Italia Saddle

*Seatpost

Size: 44, 49
Bontrager Comp, 6061 alloy, 27.2 mm, 8 mm offset, 250 mm length

Size: 52, 54, 56
Bontrager Comp, 6061 alloy, 27.2 mm, 8 mm offset, 330 mm length

*Handlebar

Size: 44, 49
Bontrager Elite IsoZone VR-SF, alloy, 31.8 mm, internal Di2 routing, 75 mm reach, 128 mm drop, 38 cm width

Size: 52
Bontrager Elite IsoZone VR-SF, alloy, 31.8 mm, internal Di2 routing, 75 mm reach, 128 mm drop, 40 cm width

Size: 54, 56
Bontrager Elite IsoZone VR-CF, alloy, 31.8 mm, internal Di2 routing, 93 mm reach, 123 mm drop, 42 cm width

Handlebar tape

Bontrager Supertack Perf tape

*Stem

Size: 44
Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 70 mm length

Size: 49
Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 80 mm length

Size: 52, 54
Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 90 mm length

Size: 56
Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 100 mm length

Brake

Shimano 105 hydraulic disc

Brake rotor

Shimano RT70, centerlock, 160mm

Rotor size

Max brake rotor sizes: 160 mm front and rear
